Gen2 - 2400W Power Station 240V - Power Controller
The new and improved Generation 2 - 2400 watt Power Controller. Suitable for homebrewers, distillers and any other means of power wattage adjustment up to 2400 watt (standard 10 amp). If you do not know if your electrical device can be reduced in power without failing, contact the manufacturer or an electrician.
We highly recommend using this product with our 2200w Weldless Element. We do not recommend plugging this unit into anything higher than a 10amp plug. Therefore you cannot use a 3600w tri-clamp element with this unit. We should also point out that if you do use this on a BrewZilla or Digiboil, that you will only be able to reduce 10-30% worth of power before the display turns off. Once the display turns off, so do the elements.
Please note; we recommend using x1 element only per Power Station Controller. If you are looking to use multiple, please ensure you have multiple Power Controllers on different circuits. If you are unsure please ask an electrician or trained professional. DO NOT EXCEED 2400W WITH THIS CONTROLLER!
From: Kegland
The Pure Distilling 1.5" Copper Bubble Plate is designed to be inserted into a 1.5" sight glass using a specially designed 1.5" Bubble Plate Seal (sold separately).
Bubble Plates are designed to promote reflux and provide visual feedback of the distillation process*.
*Results may vary, depending on your individual set-up.
KEY FEATURES
- Designed to be inserted into 1.5" sight glass
- Connects to 1.5" tri-clamp distilling accessories
WHATS INCLUDED
- Copper Bubble Plate
The Pure Distilling 2" Copper Bubble Plate is designed to be inserted into a 2" sight glass using a specially designed 2" Bubble Plate Seal (sold separately).
Bubble Plates are designed to promote reflux and provide visual feedback of the distillation process*.
*Results may vary, depending on your individual set-up.
KEY FEATURES
- Designed to be inserted into 2" sight glass
- Connects to 2" tri-clamp distilling accessories
WHATS INCLUDED
- Copper Bubble Plate
The Pure Distilling 4" Copper Bubble Plate is designed to be inserted into a 4" sight glass using a specially designed 4" Bubble Plate Seal (sold separately).
Bubble Plates are designed to promote reflux and provide visual feedback of the distillation process*.
*Results may vary, depending on your individual set-up.
KEY FEATURES
- Designed to be inserted into 4" sight glass
- Connects to 4" tri-clamp distilling accessories
WHATS INCLUDED
- Copper Bubble Plate
The mesh pieces supplied in this pack have the specifications of all being 30g +/- 1g, to ensure that the correct packing density is achieved in the column. They have been stretched and manipulated to break short strands to ensure even distribution and compaction in the condenser.
A robust thermometer/timer that allows you to set an alarm for a certain temperature.
No more need to watch the thermometer.
Yellow RAPT Pill - Hydrometer & Thermometer (Wifi & Bluetooth).
The RAPT Pill allows true real-time specific gravity and temperature logging and control via wifi/bluetooth integration (see note below) with the RAPT fermentation chamber, RAPT mobile app or RAPT IOT.
The RAPT Pill acts as both a real-time gravity testing hydrometer and thermometer allowing instant gravity and temperature measurements and also logging from inside your fermenter during fermentation.
The RAPT Pill boasts many advantages over other wireless hydrometers and thermometers including tough design, better ergonomics, sanitary design and less susceptible to error as a result of hops, krausen or CO2 bubbles generated from fermentation.
Important Note: Ensure the RAPT Pill is charged for 24 hours before use. This is to ensure that it is fully charged and the battery is callibrated.
Once the RAPT Pill is connected via USB-C and connected to wifi, the firmware will automatically update to the current version (if needed). The Pill must be plugged in via USB-C and connected to WiFi in order to receive firmware updates. A 2.4gHz network is required.
Recommended Accessory
The pill hydrometer will need to be charged periodically with a USB type C cable. Every time you open and close the pill it is possible that you have not done up the housing to the same tightness. As a result it's a good idea to mark the housing so you always do up the two halves to the same tightness or preferably re-calibrate the device. If however you purchase this Wireless Charging Kit you can avoid opening and closing the pill when charging. This greatly increases the accuracy and eliminates the need to continue to keep calibrating.
Download the App
The web wrapper application will assist in rendering the app.rap.io webpage into your mobile device screen. It also allows for push notifications to work to your mobile device.
The Google Play Android App can be downloaded via the link below.
https://play.google.com/store/apps/details?id=io.rapt
The Apple App Store RAPT App can be downloaded via the link below.
https://apps.apple.com/th/app/rapt/id1573192994
Bluetooth Bridge
Although the Pill Hydrometer will work in wifi mode the optimal solution is to use the Pill in bluetooth mode as this has several advantages including:
1. Bluetooth is more power efficient so it saves battery life. This enables the Pill to save battery by only using power efficient as it's only giving out low energy Bluetooth beacons but then the bridge device that is connected to mains power is doing the heavy lifting and transferring that data to the RAPT web portal. This is by far the most reliable way to use the Pill Hydrometer.
2. Bluetooth signal is better at penetrating through the fermenter more easily especially if you have a stainless steel fermenter or fermenter inside a fridge or fermentation chamber.
3. Bluetooth bridge mode allows you to use the Pill Hydrometer as the temperature probe to get a core fermenter temperature without the need for a thermowell. The onboard Pill Temperature sensor is also very accurate as it's an onboard digital sensor with no flexible cable. (please not if you have just charged or been in AP mode excessive heat from the battery does effect temperatures readings so wait 30min after charging for the battery temp to reach equilibrium)
4: Bluetooth connectivity allows for powerful fermentation control with the ability to use gravity and gravity acceleration to set automatic and accurate fermentation control.
To take advantage of the Bluetooth bridge mode you will need to pair the RAPT Pill to either a RAPT fermentation chamber or a RAPT Temperature Controller.
Please watch the youtube video on how to do this.
Long Battery Life
The RAPT Pill has a long battery life and can last 5 months between charges when utilising Wifi. If only using Bluetooth the battery can last 2+ years before needing to be recharged. The RAPT Pill has a USB-C charging port on the circuit board allowing fast charging from any USB-C cable.
How long will the pill last between charges?
60min telemetry frequency - 1.5 years
30min telemetry frequency - 9.5 months
15min telemetry frequency - 5 months
Note: This is the default telemetry frequency is 60 min so if you do not change the settings then out of the box the battery should last 1.5years approximately.
Pill Housing Design
The RAPT Pill housing boasts many advantages compared to other wireless hydrometers such as:
- Made from strong BPA Free Tritan Plastic
- Greater ergonomics - The shape of the RAPT Pill has been designed for improved usability compared to other wireless hydrometers such that the Pill seperates into two pieces at the midline of the Pill rather than requiring a difficult to remove end cap to be unscrewed.
- Sanitary design - The RAPT Pill has no exposed thread and a double o-ring seal which allows for a water-tight seal with reduced risk of infection.
- Less susceptible to error - The larger housing of the RAPT Pill compared to other wireless hydrometers means that the gravity logging is less susceptible to error from krausen, hops or CO2 bubbles from fermentation.
Different housing colours are sold separately, allowing customisation of your RAPT Pill.
Specifications:
- Accuracy: +/- 0.002 SG points
- Temperature Range: -20C(-4F) and up to 60C(140F)
- Pressure: 0-5bar
- Battery: Li-Ion 18650 (we use the EVE Brand)
- Size: 37mm Diameter x 125mm Long
Temperature Accuracy: +/- 0.2C (0.36F)
*Accuracy will be effected if solids are stuck to the outside of the pill hydrometer. If you shake the fermenter from time to time this generally helps to wash hops and solid chunks of krausen off the body of the Pill and through the fermentation these will generally drop to the bottom of the fermenter.
New Gravity Velocity Function
If you update your firmware we now have a new Gravity Velocity (GV) data stream that gives you the ability to automate your fermentation profiles more reliably. See this video on how to do this:
What is RAPT?
The RAPT IOT Hub is a free service whereby any RAPT enabled product can both log and store data to the hub where you can conveniently access this data. The RAPT hub can also allow you to control your devices remotely giving you absolute control of the device irrespective of where you are. The RAPT portal enables you to make complex temperature profiles that involve different temperature settings over time meaning you can start/run a temp profile giving you a set and forget experience. The RAPT portal also controls the alert/notification process for you so you can receive email notification in the off instance that something doesn't go to plan.
There is no limit to the number of RAPT devices you can connect the RAPT IOT Hub. This is in contrast to other popular wireless hydrometers where you are limited by the number of hydrometers you can connect to an app.
Please note:The RAPT Pill is fully wifi and Bluetooth capable. Bluetooth integration requires a compatible RAPT Bluetooth enabled device such as a RAPT Fermentation Chamber or RAPT Temperature Controller.
RAPT Pill - Blue Housing.
This coloured housing allows you to customise your RAPT Pill. This is purely aesthetic and means you can easily differentiate multiple RAPT Pills from each other.
Does not include clear Pill Housing, the double o-rings, or the circuit board.
From: Kegland
RAPT Pill - Clear Housing (Male Threaded - Bottom Piece).
Replace your RAPT Pill bottom housing with the RAPT Clear Housing shell. Please note there are no clear top pieces for the RAPT Pill at this stage.
RAPT Pill O-Ring sold separately.
From: Kegland
RAPT Pill - Green Housing.
This coloured housing allows you to customise your RAPT Pill. This is purely aesthetic and means you can easily differentiate multiple RAPT Pills from each other.
Does not include clear Pill Housing, the double o-rings, or the circuit board.
From: Kegland
RAPT Pill - Red Housing.
This coloured housing allows you to customise your RAPT Pill. This is purely aesthetic and means you can easily differentiate multiple RAPT Pills from each other.
Does not include clear Pill Housing, the double o-rings, or the circuit board.
From: Kegland
A replacement silicone o-ring for the RAPT Pill.
It is always wise to have a few spares in case some get pinched when tightening up the RAPT Pill.
Sold individually.
From: Kegland
Charge your Pill wirelessly with this easy-to-install upgrade kit from Kegland. The RAPT Pill is a Wifi & Bluetooth hydrometer for logging fermentation to the cloud.
This easy to install kit allows you to wirelessly charge the Pill, and also access the Pill Captive Portal without needing to open the housing to access the USB-C port!
Includes:
1 x USB-C Wireless Charging Coil
2 x Adhesive Weight Pads
1 x USB-A to USB-C cord (AU power plug not supplied)
1 x Black RAPT Wireless Charging Dock (USB-C)
If the green light does not flash green (captive portal open), it means your battery is insufficiently charged. Leave your pill on the charging pad for 24 hours or until it is fully charged (red light turns off). Then lift the Pill on and off the charging pad and it will activate the captive portal (green light will start to flash).
Note: RAPT Pill sold separately, this is for the wireless charger only.
From: Kegland
A rubber stopper (bung) with a diameter of approximately 50mm across the top, tapering to a diameter of approximately 41mm at the bottom. Fits the 23 Litre Plastic Carboy and 11.5 Litre Plastic Carboy.
The Smell Eliminator Kit completely eliminates ALL smells from the fermentation process for both beer and spirits.
Includes everything you need to attach to a standard fermenter with airlock (airlock not included).
Now you can ferment wherever is best to maintain your desired fermentation temperature without worrying about the smell.
The carbon cartridge for the Smell Eliminator Kit is made from a specially designed dense carbon block, which will last for approximately 5 brews or washes. Will not filter liquids.
Made from 304 stainless for hygiene and will last a lifetime.
Instructions: The Smell Eliminator Kit
A replacement carbon cartridge for the Smell Eliminator Kit. Made from a specially designed dense carbon block, it will last for 5 brews or washes. Will not filter liquids.
Colour liquid crystal thermometer to place on to your fermenter. Has a range of 10℃ - 36℃ going up in 2℃ increments.
This adapter connects the water flow controller to most household outdoor threaded taps and some laundry taps.
The Air Still Carbon Filter & Collection System is a simple container filter that uses a carbon cartridge to remove impurities from distillate. It is designed to filter smaller batches of spirit as produced with an Air Still or Air Still Pro.
Air Still Carbon Filter & Collection System includes:
- Carbon Cartridge
- Filter Holder
- Distillate Catcher
- Filter Container
- Filter Lid
- Clear Spindle
- Filter Bottom Cap
- Washer
• Attractive 10 L (2.5 US Gal) bench top Fermenter with Tap and Carbon Cartridge lid system to neutralise odours
• Graduated Collector for collecting from the Air Still
• Carbon Cartridge Filter System with Carbon Cartridge Holder and Filter Container
• Ceramic Boil Enhancers and Distilling Conditioner
These small ceramic chips aid the start of the boil process and help prevent surging to ensure a smooth boil. Add the Ceramic Boil Enhancers to the wash in the boiler prior to starting the boil.
Replacement bottom cap that fits the spindle on the Still Spirits Air Still Filter, EZ Filter, and EZ Inline Filter.
The Large Copper Parrot Head is a distiller’s parrot that provides the convenience of continuous, real-time, in-line ABV measurement of the spirit as it comes out of the still. Designed for use with the T500 Reflux and Alembic Distillery Systems, this proofing parrot will let you track the ABV of your distillate without having to take samples along the way. This allows you to closely monitor the quality of the distillate and determine where to take cuts or stop your distillation.
KEY FEATURES & BENEFITS:
- High-quality copper construction.
- Check your alcohol percentage during distillation without interruption.
- Compatible with the T500 Reflux and Alembic Condensers and other large stills.
- Moulded base allows the Parrot Head to sit on a bench top or table.
- Simple set up:
A: Collect the distillate as it drips from the condenser into the Parrot Head collection cone
B: Connect the Parrot Head collection pipe to the distillate out tube on the condenser.
- No need to stop distillation or move spirit to a separate collection vessel.
Fits alcometers less than 23mm in diameter. Alcometer not included.
NOTE: This unit will read no greater than 252mm from the base of your alcometer.
The Small Copper Parrot Head is a distiller’s parrot that provides the convenience of continuous, real-time, in-line ABV measurement of the spirit as it comes out of the still. Designed for use with the Air Still Pro and Air Still, this proofing parrot will let you track the ABV of your distillate without having to take samples along the way. This allows you to closely monitor the quality of the distillate and determine where to take cuts or stop your distillation.
KEY FEATURES & BENEFITS:
- High-quality copper construction.
- Check your alcohol percentage during distillation without interruption.
- Compatible with the Air Still Pro, Air Still, and other small stills.
- Moulded base allows the Parrot Head to sit on a bench top or table.
- Simple set up:
A: Collect the distillate as it drips from the condenser into the Parrot Head collection cone
- No need to stop distillation or move spirit to a separate collection vessel.
Fits alcometers less than 23mm in diameter. Alcometer not included.
NOTE: This unit will read no greater than 174mm from the base of your alcometer.
The Create+ 90° Elbow Section is designed for use with 2” tri-clamp compatible distilling systems. The stainless steel 90° Elbow Section integrates into a modular distilling system, redirecting vapour flow.
Key features:
- Connects to 2" tri-clamp distilling accessories
- 304 grade sainless steel construction
- High temperature resistent food grade silicone
INSTRUCTIONS: Insert the 90° Elbow Section into your distilling system, ensuring the silicone gasket is placed in the tri-clamp connection. Secure with a tri-clamp.
CLEANING BEFORE USE: Rinse all components with fresh, clean water before the first distillation run.
CLEANING AFTER USE: If needed, thoroughly rinse the section to remove any wash or debris. Use a non-scented brewery cleaner and a soft brush to remove any stubborn debris.
CAUTION: After distillation is complete, the surface will be very hot. Allow to cool before handling.
DISCLAIMER: Please note that in certain countries alcohol distillation and the possession of distilling equipment is illegal and permits/licenses may be required. For guidance or advice, contact your relevant local authorities.
WHATS INCLUDED
- 90° Elbow Section
- 2" Tri-clamp
- 2" Silicone Gasket
SPECIFICATIONS
- Dimensions: H 11.3 cm x W 11.3 cm x D 5.1 cm
- Weight: 0.285 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
The Create+ Multi-Tube Condenser (Shotgun Condenser) is designed for use with 2” tri-clamp compatible distilling systems. The stainless steel condenser integrates into a modular distilling system, cooling vapour by passing it through multiple tubes, efficiently condensing it into liquid.
As a product condenser, the Condenser acts as a compact yet powerful solution for efficient vapour condensation in your distillation setup. With five internal tubes designed to maximise surface area and heat exchange, it rapidly cools vapour into liquid distillate. Constructed from high-quality 304-grade stainless steel and equipped with tri-clamp fittings, it offers both durability and easy integration into any system.
As a reflux condenser/dephlegmator, when mounted vertically at the top of your column, the Condenser performs as a dephlegmator, delivering reflux control for improved separation and purity. It's short 150 mm length and five-tube layout make it ideal for hobbyists and small-scale distillers looking to precisely manage reflux and fine-tune their distillation process.
Key features:
- Works as a product condenser & reflux condenser/dephlegmator
- Connects to 2" tri-clamp distilling accessories
- 304 grade sainless steel construction
- High temperature resistent food grade silicone
NOTE: PTFE/thread tape, hoses and hose clamps are not included.
- To secure the connection we recommend wrapping the thread on both hose barbs with 2-3 revolutions of PTFE/thread tape in the clockwise direction.
- We recommend hoses with an internal diameter (ID) between 6 and 7.9mm (1/4 to 5/16”). For hoses with a smaller ID, applying hot water to the hose end may assist with assembly; for hoses with a larger ID, hose clamps may be required to ensure a secure connection.
WHATS INCLUDED
- 5-Tube Shotgun Condenser
- 2" Tri-clamp
- 2x Hose barbs
- 2" Silicone gasket
SPECIFICATIONS
- Dimensions: H 14.96 cm x W 5.1 cm x D 5.1 cm
- Port thread specification: G1/4" (BSPP 1/4")
- Hose barb specification: R1/4" (BSPT 1/4"), barb diameter 8mm
- Internal tube diameter: 11 mm
- Weight: 0.796 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
This high-quality sight glass botanical basket set is designed for use with 2” tri-clamp compatible distilling systems. This set can be used as a sight glass to monitor your distillation run or attach the mesh filters as per the instructions to convert the sight glass into a botanical basket. The sight glass will hold up to 150 g (5.2 oz) of botanicals and is suitable for fine botanicals. Compatible with 2” tri-clamp distilling systems, including the Grainfather G40/G70 Distilling Lid T500 Reflux Attachment Kit and Grainfather G40/G70 Distilling Lid T500 Alembic Attachment Kit.
Includes
- 1 x Sight glass botanical basket with 2" tri-clamp ferrules
- 1 x 2” Tri-clamp
- 2 x Mesh filters (size 10)
Instructions:
For use as a botanical basket:
- Attach the sight glass to the lid of your distilling system using one of the mesh filters and the 2” tri-clamp.
- Fill the sight glass with your desired amount of botanicals - up to a maximum of 150 g (5.2 oz).
- Put the second mesh filter on the top of the sight glass.
- Using a 2” tri-clamp connect the top of the sight glass to your condensing set up.
For use as a sight glass: Attach the sight glass to your distilling system (mesh filters are not required).
Cleaning: Clean with warm water and a suitable brewery cleaner. Using a pipe brush, clean away all residual oils on the glass. Disassembly should only be required if heavy soiling around the silicone components exists. Sanitation is not needed in this application.
Note: For use as a column extension with packing material coarse mesh is required to prevent flooding.
Specifications
- Dimensions: 246mm (h) x 100mm (w) x 100mm (d)
- Weight: 1.49 kg
CAUTION: After distillation is complete, the sight glass will be very hot. Allow to cool before handling
The Still Spirits Create+ Sight Glass Botanical Basket, the Create+ Threaded Adapter Set, and a 2" Tri-Clamp bundle allows you to convert your threaded Still Spirits T500 or Alembic condenser to a tri-clamp connection to use the the Create+ Sight Glass Botanical Basket and other 2" tri-clamp accessories with older model condensers.
Sight Glass Botanical Basket Set
This high-quality sight glass botanical basket set is designed for use with 2” tri-clamp compatible distilling systems. This set can be used as a sight glass to monitor your distillation run or attach the mesh filters as per the instructions to convert the sight glass into a botanical basket. The sight glass will hold up to 150 g (5.2 oz) of botanicals and is suitable for fine botanicals. Compatible with 2” tri-clamp distilling systems, including the Grainfather G40/G70 Distilling Lid T500 Reflux Attachment Kit and Grainfather G40/G70 Distilling Lid T500 Alembic Attachment Kit.
Key Features:
- 2" Tri-clamp connectivity
- Sight Glass constructed with 304 grade stainless steel and borosilicate glass
- Sight Glass Holds up to 150 g ( 5.2 oz) Botanicals
- 304 grade stainless steel construction
- High temperature resistant food grade silicone
Threaded Adapter Set comprised of:
- DN40 Nut
- Sieved Gasket
- Silicone Gasket
- 2" Tri-Clamp to DN40 Threaded Adapter
- 2" Tri-Clamp
Create+ Sight Glass Botanical Basket comprised of:
- 1 x Sight glass botanical basket with 2" tri-clamp ferrules
- 1 x 2” Tri-clamp
- 2 x Mesh filters (size 10)
Instructions:
For use as a botanical basket:
- Attach the sight glass to the lid of your distilling system using one of the mesh filters and the 2” tri-clamp.
- Fill the sight glass with your desired amount of botanicals - up to a maximum of 150 g (5.2 oz).
- Put the second mesh filter on the top of the sight glass.
- Using a 2” tri-clamp connect the top of the sight glass to your condensing set up.
For use as a sight glass: Attach the sight glass to your distilling system (mesh filters are not required).
Cleaning: Clean with warm water and a suitable brewery cleaner. Using a pipe brush, clean away all residual oils on the glass. Disassembly should only be required if heavy soiling around the silicone components exists. Sanitation is not needed in this application.
Note: For use as a column extension with packing material coarse mesh is required to prevent flooding.
Specifications
- Dimensions: 246mm (h) x 100mm (w) x 100mm (d)
- Weight: 1.49 kg
CAUTION: After distillation is complete, the sight glass will be very hot. Allow to cool before handling
NOTE: The Threaded Adapter Set is designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. When used with the Still Spirits Boiler 25 L lid or Alembic Dome, it is reasonably flexible and is sturdy enough to fit components within the following specifications:
A total column & condenser height up to 1.1 m (3.6 ft) from the boiler lid or dome.
A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg lbs) off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6") to the main column.
Note: The Create + Threaded Adapter Set is only suitable for use with Still Spirits Alembic Copper Condensers sold from 2019 onwards.
The Create+ Sight Glass Bubble Plate is designed for use with 2” tri-clamp compatible distilling systems. Bubble Plates are designed to promote reflux and provide visual feedback of the distillation process*. Sight Glass made from 304 grade stainless steel and borosilicate glass.
*Results may vary, depending on your individual set-up.
KEY FEATURES
- Connects to 2" tri-clamp distilling accessories
- Copper Bubble Plate with stainless steel guide ramp
- Sight Glass: Borosilicate & 304 grade stainless steel construction
- High temperature resistant food grade silicone
WHATS INCLUDED
- Sight Glass
- Copper Bubble Plate with Silicone Flat Sea
- 2" Tri-clamp
- 2" Silicone Gasket
SPECIFICATIONS
- Dimensions: H 16.7 cm x W 5.1 cm x D 5.1 cm
- Plate WT 1 mm, diameter Ø50.0±0.2. Perforations approx. Ø 2mm.
- Weight: 1.116 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
The Create+ Straight Section is designed for use with 2” tri-clamp compatible distilling systems. The stainless steel Straight Section extends the column for enhanced reflux or integrates into a modular distilling system.
Key features:
- Connects to 2" tri-clamp distilling accessories
- 304 grade stainless steel construction
- High temperature resistant food grade silicone
INSTRUCTIONS: Insert Straight Section into your distilling system ensuring the silicone gasket is placed in the tri-clamp connection. Secure with a tri-clamp.
CLEANING BEFORE USE: Rinse all components with fresh, clean water before the first distillation run.
CLEANING AFTER USE: If needed, thoroughly rinse the section to remove any wash or debris. Use a non-scented brewery cleaner and a soft brush to remove any stubborn debris.
CAUTION: After distillation is complete, the surface will be very hot. Allow to cool before handling.
WHATS INCLUDED
- Straight Section
- 2" Tri-clamp
- 2" Silicone Gasket
SPECIFICATIONS
- Dimensions: H 30.0 cm x W 5.1 cm x D 5.1 cm
- Weight: 0.583 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
The Create+ Thermowell 90° Elbow Section is designed for use with 2” tri-clamp compatible distilling systems. The stainless steel 90° elbow section with a thermowell integrates into a modular distilling system, redirecting vapour flow while enabling temperature monitoring.
Key features:
- Connects to 2" tri-clamp distilling accessories
- Integrated thermowell
- 304 grade sainless steel construction
- High temperature resistent food grade silicone
INSTRUCTIONS: Insert 90° Elbow Section into your distilling system ensuring the silicone gasket is placed in the tri-clamp connection. Secure with a tri-clamp. Secure your thermometer's sensor probe in the thermowell by using the provided plastic and silicone sleeves and the stainless steel nut. If not using a probe, seal off the thermowell using the provided stainless steel cap and O-ring.
CLEANING BEFORE USE: Rinse all components with fresh, clean water before the first distillation run.
CLEANING AFTER USE: If needed, thoroughly rinse the section to remove any wash or debris. Use a non-scented brewery cleaner and a soft brush to remove any stubborn debris.
CAUTION: After distillation is complete, the surface will be very hot. Allow to cool before handling.
WHATS INCLUDED
- Thermowell 90° Elbow Section
- 2" Tri-clamp
- 2" Silicone Gasket
- Black O-ring Gasket
- Thermowell Stainless Steel Cap
SPECIFICATIONS
- Dimensions: H 11.3 cm x W 11.3 cm x D 5.1 cm
- Thermowell compatible with Ø5 to 6mm probes
- Weight: 0.297 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
The Create+ Vented Collection Cup is designed for use with 2” tri-clamp compatible distilling systems. The stainless steel Vented Collection Cup integrates into a modular distilling system, facilitating the secure connection of distillate collection tubing while allowing safe venting of pressure during the distillation process.
Key features:
- Connects to 2" tri-clamp distilling accessories
- 304 grade sainless steel construction
- High temperature resistent food grade silicone
INSTRUCTIONS: Insert Collection Cup into your distilling system, ensure the vent weld is at least horizontal so that distillate flows out of the barbed tube, place a silicone gasket in the tri-clamp connection and secure with a tri-clamp.
CLEANING BEFORE USE: Rinse all components with fresh, clean water before the first distillation run.
CLEANING AFTER USE: If needed, thoroughly rinse the section to remove any wash or debris. Use a non-scented brewery cleaner and a soft brush to remove any stubborn debris.
CAUTION: After distillation is complete, the surface will be very hot. Allow to cool before handling.
WHATS INCLUDED
- Vented Collection Cup with Ø10 mm Barbed Tube and Vent Port
- 2" Tri-clamp
- 2" Silicone Gasket
SPECIFICATIONS
- Dimensions: H 11.3 cm x W 7.1 cm x D 5.1 cm
- Vent port/tube Ø12 mm
- Barbed tube Ø10 mm
- Weight: 0.170 kg
NOTE: The Still Spirits Boiler Lid and Alembic Dome are designed primarily for small to medium-sized distilling setups that do not have heavy, off-centre attachments. The lid and dome are reasonably flexible and sturdy enough to fit components that are within the following specifications:
- A total column & condenser height up to 1.1 m (3.6 ft) from the lid or dome.
- A total column & condenser weight up to 11 kg (24 lbs), including up to 2 kg (4.4 lbs) of off-centre weight from a swan neck, lyne arm, or condenser running in parallel with the column and offset up to 160 mm (6”) to the main column.
We recommend external support if:
- Your column & condenser exceeds the above specifications.
- The lyne arm is not vertical but angled or perpendicular running away from the column, resulting in significantly distant off-centre weight.
- If the column & condenser is noticeably leaning.
The Create+ Voltage Controller allows for better control of cuts during a spirit run. Reducing the heat input using the voltage controller will allow for a slower controlled distillation; this makes it easier to distinguish between heads, hearts and tails. Especially useful during pot distillation or vapour infusion spirit runs.
It also allows for the ability to then increase heat input as the distillate output slows towards the end of a run. This is especially useful towards the end of a pot distillation run during the ‘tails’ of a spirit run.
Designed for use with the Create+ Boiler 25 L. Electrical Safety Certified for use in New Zealand and Australia.
Specification
- Power rating: 2400W
- Plug rating: 250V AC, 10A
- Socket rating: 250V AC, 10A
- Max output current rating: 10A
- Product rated supply voltage : 220 - 240V AC
- Rated supply frequency: 50/60 Hz
- Size: 150 x 160 x 90 mm (approx.)
- Weight: 800 g
- Warranty: 12 months
