Temperature control is one of the most crucial elements for producing a good quality beer. It needs to be regulated and stable throughout the whole fermentation process to ensure the yeast doesn't get stressed and ferments correctly to get the right flavour profile.
To be able to cool with the Grainfather Conical Fermenter, you need to have the Conical Fermenter Temperature Controller. Then once your target temperature is below the temperature of the wort in your fermenter the Cooling Pump Kit pumps ice cold water through the double walled insulated interior to cool down your wort.
Simply connect the couplers and insulated hoses to the Conical Fermenter, submerge the submersible pump into a cooler box with water (add ice for your required temperature) and pump the liquid through the insulated cooling sleeve of the Conical Fermenter body.
Whats Included
Conical Fermenter Cooling Pump (submersible)
T-section power connector
2 x brass couplers
Specifications
Rated 12 VDC – 4.8 Watts
The Grainfather digital Temperature Controller replaces the temperature display. With this you can control the heating and the cooling (if you have the Grainfather Glycol Chiller) of your fermenter by dialing in a temperature or even setting a temperature schedule (can set up to 5 stages). This snaps on easily via magnets and pogo pins with no extra cords or clutter.
Specifications
Control the heating element and Glycol Chiller (available separately)
Choose between imperial and metric (C° & F°)
Total of 4 fermentation profiles with up to 5 steps each (2 are pre-set for a lager and an ale, 2 are custom)
Hysteresis is customisable and able to be set at 0.1 intervals between a range of 0.1°C – 1.9°C & 0.2°F - 2.9°F (the default setting is 0.5°C)
Automation without removing the fun of brewing, be as involved as you want to be! More automation means you can multitask or simply relax while brewing and then be alerted when to return for your next step.
Use the G30 Controller in conjunction with the Connect App (and the recipe creator) for the ultimate brewing experience.
Control Box Features:
- Bluetooth connection to your mobile device so it can be controlled remotely
- PID algorithm works in conjunction with a triac for more stable heating and so you can control power output
- Programmable step mashing
- Delayed heating - fill your Grainfather with water the night before and wake up to your water at strike temperature ready for brewing straight away
- Change between celsius and fahrenheit easily
- Waterproof graphic display
- Lugs at rear which can be changed to suit any Grainfather currently on the market
- Use in manual mode or with app
App Features:
- Grainfather Grain Kit recipes provided in app
- Import Beer XML files
- Set your own boil temperature (for different altitudes)
- Change between celsius and fahrenheit easily
- Grainfather calculators provided in app
Online recipe creator - create, share, rate and review brews through this central hub. Then when ready, sync with your app.
View the instructions online
The Grainfather counterflow chiller is used after boiling the wort to cool it down fermentation temperature. The counterflow does this by acting as a heat exchange between the wort and water from your tap as you transfer the wort from your boil kettle to your fermenter. Because this is a one-step process of transferring and cooling, it is more efficient and more sanitary than immersion chillers, and the curved design allows for similar performance to plate chillers without the crevasses that can make cleaning painful.
Features
- One step transferring and cooling
- Fast cooling time to within 3C of source water temperature.
- More sanitary transferring
- Copper inner coil for high heat exchange
- Compatible with a range of brewing systems
Includes
- Counterflow chiller
- G30 connector
- 9mm right angle hose barb connector for G40, G70 and other brew systems
- Tap adapter set for connection to garden hoses and most faucets
Specifications
- Copper inner coil
- 9mm ID inlet and outlet hoses
- Colour coded hoses for inlet and outlet water
The Electric Grain Mill is motorised, compact and easy to use at home. It’s equipped with large, fluted rollers that crack the outer husk of the grain longitudinally, providing optimal surface area for your mash and a better filter bed for your sparge.
The removable grain hopper holds up to 1kg of grain at a time and with 10 easily adjustable gap settings, ranging from 0.8mm to 2mm, this mill has been engineered to crush a variety of grains. Crush different base malts and specialty grains, and even change the rate that your grain is crushed with the variable speed dial.
It’s easy to mount onto a workbench or bucket, but it works best with the Grain Mill Bamboo Mounting Board. Plus, the mill is easy to assemble thanks to its built-in motor and compact design. Simply attach the grain hopper. Set your desired gap setting by pulling the spring-loaded pin and rotating the dial. Add grain to the hopper and flick the switch to begin crushing.
Now you can create fresher batches of beer by bulk buying your own grain and crushing it at home, just before you brew.
Specifications
- Voltage: 220 - 240V
- Frequency: 50Hz
- Power: 400W
- Rollers: 58mm diameter and made of hardened stainless steel with a flute design that’s akin to commercial grain mills
- 10 mill gap settings: 0.8mm - 2mm
- Crush rate: up to 1.7kg of grain per minute
- Grain hopper capacity: 1kg
The Electric Grain Mill is motorised, compact and easy to use at home. It’s equipped with large, fluted rollers that crack the outer husk of the grain longitudinally, providing optimal surface area for your mash and a better filter bed for your sparge.
The removable grain hopper holds up to 1kg of grain at a time and with 10 easily adjustable gap settings, ranging from 0.8mm to 2mm, this mill has been engineered to crush a variety of grains. Crush different base malts and specialty grains, and even change the rate that your grain is crushed with the variable speed dial.
Included is the Grain Mill Bamboo Mounting Board making it easy to mount onto a workbench or bucket. Plus, the mill is easy to assemble thanks to its built-in motor and compact design. Simply attach the grain hopper. Set your desired gap setting by pulling the spring-loaded pin and rotating the dial. Add grain to the hopper and flick the switch to begin crushing.
Now you can create fresher batches of beer by bulk buying your own grain and crushing it at home, just before you brew.
Specifications
- Voltage: 220 - 240V
- Frequency: 50Hz
- Power: 400W
- Rollers: 58mm diameter and made of hardened stainless steel with a flute design that’s akin to commercial grain mills
- 10 mill gap settings: 0.8mm - 2mm
- Crush rate: up to 1.7kg of grain per minute
- Grain hopper capacity: 1kg
The Grainfather Fermentation Thermometer is a simple analogue thermometer that can easily be inserted into the Grainfather SF70 Thermowell to measure the temperature of the fermentation
It provides an accurate reading in both Celsius and Fahrenheit.
A set of tap adapters to enable tubing for the Grainfather Counterflow chiller to be connected to an indoor or out door tap.
Could also be used to connect tubing for other equipment, such as the Filter - Beer & Water Filtering System, to an indoor or out door tap.
Convert the Recirculation Arm and the Counter Flow Chiller of the Grainfather to convenient Camlock fittings.
This upgrade kit consists of 5 stainless steel parts to convert the Grainfather Recirculation Arm and Wort Chiller to easy to use Camlock fittings.
Watch David Heath's YouTube video above for more information and installation instructions.
Click here for an installation guide.
Kit contains:
-
BSP Hex/Reducing Bush 1/2 Inch - 3/8 Inch
- Camlock - Female to 1/2 Inch Female D Type
- Camlock - Male to 1/2 Inch Female A Type
- Camlock - Male to 1/2 Inch Barb E Type
- Compression Fitting - 12.7mm to 1/2 Inch BSP
Please measure the diameter of your Grainfather Recirculation Arm to ensure the compression fitting will fit.
Upgrade the Grainfather G30 Brewing System with the G30 Hop Plate, a purpose-built false bottom style hop plate filter for use with all G30 Brewing Systems. Install alongside the system's current filter for increased efficiency in hop filtration.
How to Use:
1. Install the G30 Filter (this is the hop filter included with the G30) as per the instructions included with the G30 Brewing System.
2. Install the G30 Hop Plate by placing the plate feet down into the boiler over the top of the G30 filter, so the feet of the hop plate rest flat on the base of the boiler.
Features:
- Sleek, high-quality 304 grade stainless steel construction
- Easy to clean
- Full body false bottom style filter for even better hop filtration
- Designed specifically for use with the G30 Brewing System
Specifiations:
- 304 stainless steel construction: (0.9 mm Thickness)
- Outer diameter (width): 29.5 cm
- Height: 5.1 cm
- Perforation diameter: 1.8 mm
- Carton dimensions: 32 cm x 32 cm x 0.9 cm"
Note: Some users may experience a slight reduction in boil vigour and a slight increase in heating time.
Caution: Post-boil hop matter will retain heat. Always use thermally insulated gloves when removing the hop plate post boil.
Replacement RM10 Pump for the Grainfather G30. Includes screws for the pump housing.
Upgrade your G30 and enhance your brewing experience with these rolled plates. Replace the standard G30 plates that come with silicone seals and make assembling and cleaning your grain basket a whole lot easier.
- 304 grade stainless steel
- Rolled edges
- Outer diameter (width): 267mm
Replacement rolled edge grain plate with handle for the Grainfather G30v3. This plate is to be used with the perforated grain basket and can be used as a top and bottom plate. Not recommended for use with G30 baskets pre G30v3.
This item is not held in stock and is ordered in on request. Please contact to check availability and shipping cost.
The Grainfather G40 is a brewhouse brewing system that handles the hot side of the all-grain brewing process. This unit has the ability to produce up to 40L (11 US Gal) of wort from one brew. Connect your mobile device to the smart controller with built-in wireless control via the Grainfather App, for step-by-step brewing and access to 1000s of recipes.
The G40 is capable of transforming into a home distillery with the G40 and G70 Distilling Lid & Attachment Kits.
Add the Grainfather G40, G70 & SS Fermenter 1/2" Tap or Ball Valve Assembly 316 Stainless Steel - 1/2 Inch to enable quick drainage from the bottom of the unit making CIP a breeze.
FEATURES:
- Sleek 304 grade stainless steel body
- Heats wort evenly with large, surface mounted heating elements
- Connect your mobile device to the smart wireless controller via the Grainfather App and manage your brew remotely
- Conical base for maximum wort transfer
- Efficient and sanitary brew transfer with the counterflow wort chiller
- PID heating control for accurate temperature management during mashing
- Quick and easy cleaning with CIP (clean in place) capability
- Integrated sight glass for easy volume reading
- Rolled edge mash plate and large hop filter to reduce blockages
- Compatible with 10 and 15 amp modes (15 amp NZ/AU only)
SPECIFICATIONS
SIZE: 650 x 530mm
WEIGHT: 29kg
BOX DIMENSIONS: 62cm x 57cm x 72.5cm
BOXED WEIGHT: 34.7kg
CAPACITY: 46L (12 US gal)
BATCH VOLUME: Max: 40L Min: 10L
GRAIN BILL: Max: 13kg Min: 3kg
POWER: NZ, AU: 2300 - 3200W, 230V UK: 2900W, 230V US, EU: 3300W, 230V
CONNECTIVITY: Wireless control
WHAT’S INCLUDED?
- Grainfather G40
- Smart controller with built-in wireless connectivity
- Counterflow wort chiller
- Glass lid
- Lifting bar
- Inner basket
- Recirculation hose
- Grain plate
- Hop filter
- Fittings
- 10amp power cable
Click here for the G40 instruction booklet.
Click here for the G40 technical specifications.
Replacement part Recirculation & Sight Glass Pipework for the Grainfather G40 Brewing System. Contains stainless steel and plastic components.
For use with the G70 and G40 to allow quick drainage from the bottom of the unit. Made with high temperature resistant 304 grade stainless steel, the faucet’s operating temperature ranges from -10°C to 150°C.
Alternatively you could use the Ball Valve Assembly 316 Stainless Steel - 1/2 Inch.
Replacement Glass Lid for the Grainfather G40 or the G70 Brewing Systems. Compatible with all versions of the G70.
Transform the G40 or G70 Brewing System into a home distillery with the G40 & G70 Distilling Lid. This lid features an industry standard 4” tri-clamp opening to allow for the connection of the Still Spirits T500 Reflux and Alembic Condensers, as well as third-party distilling equipment. Note: We will be launching Accessory Attachment Kits for the T500 Reflux and Alembic Condensers in the first quarter of 2023.
Features:
-
304 Grade Stainless Steel Construction
-
Standard 4” tri-clamp opening (industry standard)
-
Pressure relief valve
-
Barrel clamp locking mechanism
The ultimate bundle to pair with the T500 Alembic Condenser allowing you to turn your G40 or G70 Brewing System into an all-in-one automated Brewing System that can also be used for pot distillation. Bundle includes the G40 & G70 Distilling Lid plus the T500 Alembic Condenser Attachment Kit so you can brew quality beer and distill whiskey, bourbon, rum, and more.
FEATURES
Lid & Attachment Kit:
- 304 Grade Stainless Steel Constructions
Attachment Kit:
- Copper Helmet to Aid in Reduction of Sulphur Compounds and Retention and Development of Flavour
- Lid:
- Standard 4" tr-clamp opening (industry standard)
- Pressure relief valve
- Barrel clamp locking mechanism
Note: Still Spirits T500 Alembic Condenser sold separately
WHATS INCLUDED
G40 & G70 Distilling Lid
T500 Alembic Condenser Attachments Kit includes:
4” Tri-Clamp
4” Tri-Clamp Seal
4” to 2” Copper Alembic Helmet
2” Tri-Clamp
2” Tri-Clamp Seal
2” to ½” (48mm) DN40 Thread Adapter
Condenser Silicone O-Ring
SPECIFICATIONS
Lid & Attachment Kit:
304 Grade Stainless Steel Construction
Lid:
Standard 4” tri-clamp opening (industry standard)
Pressure relief valve
Barrel clamp locking mechanism
Attachment Kit:
Copper Helmet to Aid in Reduction of Sulphur Compounds and Retention and Development of Flavour
The G40 & G70 Distilling Lid plus the complete set of fittings to connect the T500 Reflux Condenser (stainless steel or copper) to either the G40 or the G70 for reflux distilling.
The ultimate bundle to pair with the T500 Reflux Condenser stainless steel or copper), allowing you to turn your G40 or G70 Brewing System into an all-in-one automated brewing system that can also be used for reflux distillation. Bundle includes the G40 & G70 Distilling Lid plus the T500 Reflux Condenser Attachment Kit so you can brew high quality beer and distill neutral spirits.
INCLUDES
- G40 & G70 Distilling Lid
- Standard 4" tri-clamp opening (industry standard)
- Pressure relief valve
- Barrel clamp locking mechanism
- 2” to ½” (48mm) DN40 Thread Adapter
- 2” Tri-Clamp Seal with Mesh
- 2” Tri-Clamp
- 4” to 2” Tri-Clamp reducer
- 4” Tri-Clamp Seal
- 4” Tri-Clamp
- 304 Grade Stainless Steel Construction
Note: T500 Reflux Condenser sold separately
A complete set of fittings to connect the G40 & G70 Distilling Lid to the Still Spirits T500 Alembic Condenser for pot distilling.
The G40 or the G70 paired with the Distilling Lid and T500 Alembic Condenser Attachment Kit offers an all-in-one automated brewing system that can also be used to for pot distillation, making it the ultimate combo to brew high quality beer and distill whiskey, bourbon, rum, and more.
INCLUDES
- 4” Tri-Clamp
- 4” Tri-Clamp Seal
- 4” to 2” Copper Alembic Helmet
- 2” Tri-Clamp
- 2” Tri-Clamp Seal
- 2” to ½”(48mm) DN40 Thread Adapter
- Condenser Silicone O-Ring
FEATURES
- 304 Grade Stainless Steel Construction
- Copper Helmet to Aid in Reduction of Sulphur Compounds and Retention and Development of Flavour
Note: Distilling Lid & Still Spirits Pot Still Alembic Copper Condenser sold separately.
A complete set of fittings to connect the G40 & G70 Distilling Lid to the Still Spirits T500 Reflux Condenser (stainless steel or copper) for reflux distilling.
The G40 or the G70 paired with the Distilling Lid and T500 Reflux Condenser Attachment Kit offers an all-in-one automated brewing system that can also be used for reflux distillation, making it the ultimate combo to brew high-quality beer and distill neutral spirits.
INCLUDES
• 2” to ½” (48mm) DN40 Thread Adapter
• 2” Tri-Clamp Seal with Mesh
• 2” Tri-Clamp
• 4” to 2” Tri-Clamp reducer
• 4” Tri-Clamp Seal
• 4” Tri-Clamp
• 304 Grade Stainless Steel Construction
Note: Distilling Lid and T500 Reflux Condenser sold separately
