• 0-40psi / 0-250kPa / 0-2.5 Bar (kg/cm^2)
• Rubber Coated
• 8mm Push in Barb

This item is not held in stock and is ordered in on request. Please contact to check availability and shipping cost.

RAPT Temperature Controlled Fermentation Chamber

This fermentation chamber has been designed to heat and cool your entire fermenter.  This is the ideal scenario as the whole fermentation vessel is placed in a temperature controlled environment which gives you the most even temperature and most precise control of your fermenter.

Many home made products can greatly be improved with perfect temperature control.  The RAPT Temperature Controlled Fermentation Chamber gives you an electrically efficient means of setting, monitoring and controlling temperature which is perfect for Beer Making, Wine Making, Salami Making, leavening bread, fermenting yogurt, kombucha, germinating seeds, growing sprouts, kimchi, sauerkraut, olives, cheese, making spirit washes.  Accurate temperature control is the key to getting reliable and repeatable results.

From -2°C up to 50°C all at the touch of your fingertips!

The control panel comes complete with an integrated colour TFT screen, the integrated secondary regulator that can be used to regulate gas into the chamber with our Inline Regulator with an integrated gauge or alternatively this can be switched over to the Gauge integrated BlowTie unit to regulate residual pressure in your fermenter.  The 4 button colour display conveniently shows a log of historic temperature graphs, allows you to start, set/stop temperature profiles and gives you access to other critical information for that particular fermentation.
For more accurate readings of the core temperature of your fermenter. We highly recommend using a thermowell like our 60cm duotight thermowell with the 2m probe extension for the RAPT Fermentation Chamber.

Perfect as a Kegerator too!
This multi purpose chamber can also be used as a kegerator.  In particularly cold climates where the ambient temp is below zero, this chamber can warm your kegs and prevent them from freezing.  This chamber also has a higher keg storage capacity than a conventional kegerator that takes up the same footprint.  This unit can hold 4 x 19L kegs on the floor and has enough headroom that you can also fit another layer of 9.5L half size kegs above this.  To fit beer taps, you can drill your own holes through the door.

Convert to Display Chamber
This Chamber comes with brushed stainless steel PU foam-filled door.  If you want to upgrade to a glass door the double glazed glass door can be purchased separately and switched over - coming soon.

What is RAPT?
RAPT is a dedicated Internet of Things (IOT) Hub for fermentation logging and control.  It's a free service whereby any RAPT enabled product can both log and store data to the hub where you can conveniently access this data.  The RAPT hub can also allow you to control your devices remotely giving you absolute control of the device irrespective of where you are.  The RAPT portal enables you to make complex temperature profiles that involved different temperature settings over time meaning you can start/run a temp profile giving you a set and forget experience.  The RAPT portal also controls the alert/notification process for you so you can receive email notifications in the off instance that something doesn't go to plan.

Specifications:
Integrated Heating: 50watt Heating Power
Cooling Capacity: 300watt Cooling Power
Max Power Consumption: 225 Watts
Refrigerant: r600a
Connectivity: Wifi (802.11) and Bluetooth
Temperature accuracy: +/- 0.1C
Temp Resolution: 0.1C
Integrated Screen: 2.8inch (diagonal) 320 x 240 Colour LCD TFT Active Matrix

External Dimensions:
Width: 540mm
Depth: 610mm
Height: 1760mm

Internal Dimensions:
Width: 440mm
Depth: 500mm
Height: 1300mm

To see the dimensioned drawings on this part click here.

Why buy an insulated fermentation chamber over a glycol chiller?
Typically in the past, some customers have needed to resort to glycol chillers to chill fermenters but this represents several issues:

1. Glycol chillers often require a very cold liquid to enter into a fermenter causing an excessively cold part in the fermenter core.
2. Glycol chillers consume significant amounts of power and in most instances more than double what this chamber would consume.
3. Glycol chillers often result in spilling sticky glycol especially when hoses are connected and disconnected to the fermenter.
4. Glycol chillers generally require penetrations through the walls/lid of the fermenter making the fermenter less sanitary and requiring more cleaning. "who needs that!"
5. Often fermenters are not made with sufficient insulation.  So when using a glycol chiller much of the chilling is lost which is not only power inefficient but the customer ends up with a large temperature gradient.  This temperature gradient can result in convection currents in the fermenter that make it difficult for yeast and other solids to settle out of suspension.  So clarification of the beer takes significantly longer.
6. Many glycol chillers and fermenter combinations do not have sufficient power or are not well enough insulated to cool to sub-zero temperatures.  So crash chilling is not possible.  This is a significant compromise to a temperature-controlled solution and also results in less ability to clarify the finished beer.

For these reasons KegLand has developed the worlds first dedicated RAPT enabled fermentation chamber that can cool down to -2C and heat up to 50C even in hot and cold weather.

The Google Play Android App can be downloaded via the link below.
https://play.google.com/store/apps/details?id=io.rapt

"This app is a web mobile wrapper that allows you to browse the RAPT portal/website so that the website renders into a mobile device screen increasing usability on your device.  It also gives you the added functionality of push notifications to your mobile device."

From: Kegland

A replacement o-ring for the 30L and 60L barrel fermenter lid.

Silicone Stopper / Bung for Ss Brew Buckets made from food grade silicone.

The Smell Eliminator Kit completely eliminates ALL smells from the fermentation process for both beer and spirits.

Includes everything you need to attach to a standard fermenter with airlock (airlock not included).

Now you can ferment wherever is best to maintain your desired fermentation temperature without worrying about the smell.

The carbon cartridge for the Smell Eliminator Kit is made from a specially designed dense carbon block, which will last for approximately 5 brews or washes. Will not filter liquids.

Made from 304 stainless for hygiene and will last a lifetime.

Instructions: The Smell Eliminator Kit

A replacement carbon cartridge for the Smell Eliminator Kit. Made from a specially designed dense carbon block, it will last for 5 brews or washes. Will not filter liquids.

Introducing the all new Brew Bucket 2.0

Nearly a decade after the Brew Bucket was first produced, Ss Brewtech challenged the Ss Engineering Team to pair some of the newest technologies with the original design.

Replacement Lid Seal for SS Brewtech Brew Buckets and Chronicals; made from brewer's grade silicone.

These also fit the FTSs lids at the matching size.

From: Ss Brewing Technologies

Colour liquid crystal thermometer to place on to your fermenter. Has a range of 10℃ - 36℃ going up in 2℃ increments.

Screw-in tap for use with Handcraft Supplies 30L Wide Mouth Fermenter. Simply screw the tap in the pre-drilled hole at the bottom of the fermenter before filling the fermenter with your ingredients. Mangrove Jack's Silicone Hose 100mm is required to connect the tap to a brew bottler. Not compatible with sediment reducer.

Temp Twister Pump Kit with Return Line and Clamp.

If a glycol chiller is a bit out of reach at the moment, but you want to use the Temp Twister in your Kegmenter or FermZilla, this little product can help you on your way to cool your fermenter. Simply submerge the pump in a large bucket with water and ice.

The more insulation you give your fermenter and keep it at a relatively stable temperature the better. We suggest using this in conjunction with a temperature controller.

Parts List:
1 x 1.2m Length of Insulated 6mm x 9mm EVABarrier Hose
1 x 1.2m Length of 6mm x 9.5mm hose (return line back to the bucket) (colour may vary)
2 x 9.5mm duotight Elbows (For temp twister)
1 x Temp Twister 12v Pump and power supply

From: Kegland

A stainless steel, 1/2" thread, weldless thermowell (takes any probe up to 7mm ID).

This thermowell works great with any kegmenter, keggle, brew pot, boiler and various other brewery hardware to get an accurate core temperature of your vessles.

This thermowell has a 7mm bore, so it's ideally suited to any probe type up to 7mm.  Most probes are 6.5mm or smaller in diameter meaning they will fit nicely into this well.  It's ideal for the RAPT Temperature controllers.

This is a weld free design so all you need to do is drill a 20mm hole and file this out a fraction and this will go right into the hole with no welding required.  The threads have been designed to be sanitary so you just screw it against your vessel wall and none of the threads will be exposed to liquid. The soft silicon seals will seal against curved surfaces of your pots and other vessels.

If you want to make a really smooth hole easily in your vessel walls we recommend the use of a step drill bit and 20mm hole punch.

Length: approx. 100mm
From: Kegland

A 1.5" tri-clamp thermowell fitting from Krome Dispense that is approx. 15cm long.

- 304 Stainless Steel
- Approx. 15cm thermowell

Does not include tri-clamp clamp or gasket.

From: Krome Dispense

This thermowell fits into any 8mm Hole and can literally be installed into almost any fermenter lid.

Having the thermowell attach to the lid of a fermenter is ideal as it means the penetration through the fermenter body is at the top of the fermenter not below the liquid line. This makes the whole process more sanitary and reduces the number of difficult parts to clean.

This thermowell can be pushed through a bung with a 6-8mm hole but it also includes the Duotight bulkhead fitting that you can use to attach this thermowell to the lid of your FermZilla Fermenter.

It goes right into the middle of the core of your vessel meaning you get an accurate core reading of the liquid in the tank/vessel.

Note: If you need to shorten the length of this thermowell tube then simply use a tube cutter to the desired length.

Made from: 304 stainless steel
Dimensions: 8mm OD x 7mm ID
From: Kegland

Tri-Clamp Cap to Ball Lock Post fitting, with both liquid and gas post options. These 1.5" tri-clamp fittings provide a sanitary and leak-proof connection, and can be used with our ball lock connectors. The price is per single unit - gas or liquid - not for pair like in the photos.

From: Krome Dispense
Material: Stainless 304
